ADL Data Examples

The Alexandria Digital Library is loading, over time, the collections of many participants. This includes spatially indexed collections of the U.C. libraries and archives, selected California State University holdings, state and federal agency publications and private research contributions. Geographically our plan is to grow the georeferenced holdings from California outward. We are loading synoptic datasets first followed by more detailed narrower-scoped materials. Detailed digital information at the state level is widely scattered, thus ADL will focus on existing historic maps, reports and aerial photography of California building out from Santa Barbara to other state locations.  Another equally important consideration will be the condition of the original materials. Those objects in poor condition will be scanned and loaded first so as not to lose any historic content.

Three categories of "collections" are initially being loaded into the Alexandria Digital Library (ADL). They are:

  • Collections of metadata for both on and off-line data holdings
  • A gazetteer (place name index) of 6.5 million earth locations, and
  • Digital data that can be linked to, browsed, and downloaded to desktop applications.

For term definitions, shown in black Italics, see the glossary at the end of this document.

The ADL metadata collections are comprised of bibliographic records at the item level. This means that each data object represented in the library has its own catalog entry. As an example, each of the 65,000 topographic maps of the United States has its own entry in the catalog. These records may also have what is termed a parent catalog entry; information that is shared in common with all data objects belonging to a single publication project. Each record describes a library data object whether online or still residing in its paper form. The ADL catalog contains about 750,000 bibliographic records at this time.

The ADL gazetteer, another name for a place-name index, allows a user to find earth features by typing in the name associated with that feature, e.g., find the city of Santa Barbara or find all references to the name "Santa Barbara" worldwide. The gazetteer database may be used as a spatial finding aid or as a stand-alone reference tool.

The ADL data archive is a growing set of digital files that may be accessed online. Initially ADL plans to focus on California with a few other demonstration sets of other parts of the world. These California data are comprised of digital map, text and imagery files of varying detail starting from a space perspective and "drilling-down" to detailed earth features (see footprint diagram below). These datasets are briefly described below starting with those with the least earth detail and proceeding to those with the most detail. In the examples below, imagery datasets are listed first, followed by mapping datasets. No example of a spatially referenced text document is supplied in this overview.

Imagery

SPACE-PIX

 SPACE-PIX: These space-shuttle images cover selected regions of the Earth and give a synoptic but minimum detailed look at selected Earth locations: expect detail at the level of cities and mountain ranges. These images differ from the following AVHRR image in that they are color and are often captured at an oblique angle. ADL currently has about 3000 of these images scattered around the earth. The smallest ground detail that can be recognized is about 2 kilometers.

Example of a Space-Pix space shuttle image

AVHRR

AVHRR imagery is constantly changing. It is captured from a satellite at regular intervals during the day and night. This imagery has a ground detail of about 1 kilometer and is in black and white. Since this data is made available via ADL in close to real time, only the most current images are offered. The data is linked via ADL from a remote Internet site. It takes one or two images to cover all of California. This data may be used to observe weather conditions, track forest fires, or the effect of flooding from El Nino.

Example of an AVHRR image

Thematic Mapper Imagery [TM]

Thematic Mapper Imagery [TM] is medium scale satellite data. It has a ground detail of about 20 to 30 meters and has 7 channels of image data that may be viewed singly or in combinations. The data is used for vegetation analysis, urban planning, geology and many other forecasting and research areas. ADL has georectified tiles for all of California. Please refer to fig. A for ground-area footprint. Currently there are about 30 tiles that cover all of California.

Example of a Thematic Mapper Image

Spot

Spot Images for California are also satellite data and ADL contains tiled images for the whole state. This data is only licensed for U.C. research. The images are black and white tiles with a ground detail of about 10 meters. There are about 185 tiles in this dataset that cover all of California.

Example of a Spot Image

Digital Orthophoto Quadrangles [DOQ]

Digital Orthophoto Quadrangles [DOQ] are digital "image-maps" in that they coincide with existing printed USGS Topographic maps but reveal photographic features. They have a ground detail of about 1-meter. Currently, about half of California, mostly urban areas are complete. ADL has loaded about 7,000 files of the 15,000 that will be available when the publication is complete in 2001. This imagery is georectified and can thus be used with standard USGS topographic maps.

Example of a Digital Quadrangle

Historic Aerial Photography

 Selected detailed historic aerial photography of California are being scanned. This is an ongoing program for making unique historic California aerial photography housed at UCSB and other archive locations web available. Currently about 4,000 images have been scanned ranging in dates from 1928 to the present. The ground detail of these images is about ½ meter. The geographic region being scanned by ADL in 1998 is urbanized Southern California. This will be expanded to other California sites as contributions from other participating archives are added to ADL.

Example of Historic Aerial Photography

Map Sets

ADL will also provides access to various map sets, including the examples below. Two types of data are initially being loaded by ADL; digital elevation models (contour relief maps) and scanned topographic maps. Complete sets for California will be available through ADL. Please refer to figs. A and B for geographic footprint information.

Digital Elevation Models

Digital Elevation Models [DEM] are available in two scales; 1:250000 and 1:24000. The former has a ground detail of about 80 meters and the latter a detail of about 30 meters. They are used for showing physical terrain and as a basic level dataset for many mapping applications. When used with Spot or DOQ images a 3D model of an area may be constructed. ADL will provide access to both datasets. The series contain about 3350 files for the State.

Example of a Digital Elevation Model



Digital Raster Graphic

Digital Raster Graphic [DRG] maps are scanned topographic maps at a scale of 1:24000. They have a ground detail of about 30 meters and are produced by the United States Geological Survey. Each map is georectified and may be used in conjunction with the corresponding DOQ data. Currently, ADL is working with the California Teale Data Center and the USGS to make these digital maps available. There are about 3300 files for California in this series.

Example of a Digital Raster Graphic

Other Datasets Being Loaded for Educational Instruction

Sierra Nevada Ecosystem Project

Sierra Nevada Ecosystem Project (SNEP) – This dataset is comprised of maps, GIS coverages, text and images. This NSF funded research project was completed in 1997 and represents the eco-environment of the Sierra Nevada geographical area. It covers large sections of California and Nevada wilderness and is actively used for research and teaching.

Example of a Sierra Nevada Ecosystem Project Image

CIA Country Maps

 CIA Country Maps –These scanned maps of various scales cover all of the world’s countries. They represent a basic worldwide dataset for educational instruction. There are about 350 map files accessible through ADL

Example of a CIA Country Map

Glossary of Terms

  • AVHRR – Advanced Very High Resolution Radiometer: an image sensor on an earth satellite.
  • Channels – multiple images captured by imaging sensors of the same location, at the same time, but at different wavelengths of light.
  • Datasets – groups of data objects that may be described as a single unit e.g., Encyclopedia Britannica.
  • Desktop Applications – personal computer applications such as PhotoShop or Microsoft Word.
  • Gazetteer – place name index showing an earth feature such as a city along with its geographic location.
  • Georectified – spatial data that has been computer processed so as to match Earth locations exactly.
  • Image-Map - a map that has its features presented photographically rather than hand or machine drawn.
  • Metadata – information about a data object; a bibliographic catalog record describing the data unit.
  • Tiles – data that has been cut into "pages" so they can be viewed one-at-a-time or stitched together.
  • Topographic maps – maps that show contour lines of equal elevation in addition to other Earth features.

Footprint Diagrams

Example of a Footprint Diagrams
